70KG High Frequency Linear Vibration Welder

70KG High Frequency Linear Vibration Welder

MSV-SF70 is a high frequency vibration welder with upper jig loading ability of 70KG. Machine output vibration in frequency max to 365Hz. Machine vibration can start in amplitude in 0.02mm, which limits little to the design of plastic parts in geometric shape.

This machine is a medium specification vibration welder which can be applied to weld plastic parts in the most measurement. For automotive manufacturing, 70KG vibration welder is mostly applied to weld air inlet manifold for engine, drawer of IP, tail lamp, etc.

SF series vibration welder achieves clean vibration thermoplastic welding without preheating. The performance is the more stable, more economical and higher efficiency.



Technical description

I Features:

 1. Auto-tuning the frequency after jig loading;

 2. Welding process steps control to meeting different high thermoplastic vibration joining requirement;

 3. Operation mode can be time mode or depth mode;

 4. 80 sets of welding parameter storage;

 5. Welding quality judgment help quality management;

 6. Internet connection function is available;

 7. Printing function is designed.

 8. Higer frequency vibration welding in lower amplitude:

  •  -Low welding amplitude minimizes the limit to part design by vibration motion distance and slope angle, realizing flexible part design;

     -No need preheating to parts before welding, achieving operation in high efficiency,  economical spending, low cost & stable performance.

  • -Vibration welding in high frequency & low amplitude,  no material flush dropping into welded parts;

II Specification:

 > Model: 730LS

 > Weight upper tool: 70kg

 > Welding area(approx):  460cm2

 > Amplitude(peak to peak): 0.2~1.8mm

 > Frequency: 280~365HzMachine Dimension: 2554x1240x2240

 > Front Door Opening: 1500x790(mm)

 > Drive Platen/upper : 1020x540(mm)

 > Lift Table Size: 1500x600(mm)

 > Table stroke: Max. 500 mm

 > Max. distance between lift table&Vibration Head: 735mm

 > Table Elevating Speed: 250mm/s

 > Clamp Force: 32kN

 > Hydraulic System: Servo Pump

 > Hydraulic oil: ISOVG32

 > Weight: about3700kg

 > Sound pressure level: <85dB

 > Main voltage(3P)/Input: AC220V/50,60Hz / AC380V ,440V

 > Power consumption: 47KVA

 > Maximum Power/Out Put: 30Kw

 > Control Voltage: DC 24V

 > Frequency Tuning: Auto/Manual

 > Auto Tuning: about 4Sec.

 > Welding Control: Depth/Time

 > Step for Welding: 8Stage

 > Set up number: 80ea

 > Welding Result Analysis: Good/Bad

 > Language: English/Chinese/Korean

 > Internet: Yes

 > Communication: Yes

 > Printer Terminal: Yes

Optional Features:

  > SPC;
